ყურის მონიტორის გადამცემი სისტემა NUX Wireless System B-7Pro

Specifications

• Product Code: NUX B-7 PRO
• Operating Frequency Band: 2400-2483.5 MHz
• Transmit Mode: Frequency Hopping
• RF Output Power: 10 mW E.l.R.P. max
• Audio Quality: 24-bit/48 kHz
• Frequency Response: 20Hz-20kHz
• Latency: 7.33 ms (low latency setting) – 10.85 ms (default) – 14.33 ms (safe setting)
• Unbalanced Input Impedance: 10kΩ
• Balanced Input Impedance: 20kΩ
• AUX Input Level: 2.1 Vrms (8.7 dBu) max
• Balanced Input Level: 9.8 Vrms (22 dBu) max
• Headphone Output Impedance: Minimum 13Ω
• Headphone Maximum Output Power Per Channel: 57 mW (THD<0.1% RLOAD=16Ω,1 kHz)
• Channel Separation: −105 dB
• THD+N: <0.01% typical
• Dynamic Range: 110 dB A-weighted
• Output Level Adjustment Range: Mute −86 dB ∼ +12 dB
• Auto-Off: Automatic switch-off after 10 minutes without signal
• Built-in Battery Capacity: Rechargeable Li-polymer (Transmitter 3.7 V/3000 mAh, Receiver 3.7 V/400 mAh)
• Battery Lifetime:
  • Transmitter: Up to 6 hours
  • RX: Up to 6 hours
• Power Requirements: DC 9V, 1A min, negative tip power supplies (Transmitter)
• Operation Range: Up to 50m (165 feet) maximum
• Transmitter Dimensions: 140 mm x 97 mm x 53 mm (L x W x H)
• TX Weight: 525 g
• RX Dimensions: 47 mm x 71 mm x 22 mm (L x W x H)
• RX Weight: 51 g
