ანალოგური მიქშერი Alto LIVE2404

THD+N: < 0.03% at 0 dBu, 1 kHz

Sensitivity Range: -15 dBu to 30 dBu

Channel Insert Return: 200 Kohm

All Other Inputs: >100 Kohm

2-Track Outputs: 10 Kohm

All Other Outputs: 20 Kohm

Mid-Bell (mono): ±15 dB sweep able from 100 Hz — 8 KHz,

Low-Shelving: ±15 dB @ 80 Hz

Stereo Channels: High-shelving: ±15 dB @ 12 kHz

High-Mid-bell (mono): ±15 dB @ 3 KHz

Low-Mid-bell (mono): ±15 dB @ 500 Hz

Low-shelving: ±15 dB @ 80 Hz

Main EQ: 9 EQ bands (63 Hz, 125 Hz, 250 Hz, 500 Hz, 1 kHz, 2 kHz, 4 kHz, 8 kHz, 16 kHz), ±15 dB

DSP Resolution: 24-bit

Effects: 10 DSP effects families with 10 variations available per family

Presets: 100 total

Controls: Rotary encoder to select preset, DSP mute switch, peak LED indicator

Fader 0 dB, channels muted: -84 dBr (ref: +4 dBu)

Fader 0 dB, all input channels assigned & set to unity gain: -73 dBr (ref: +4 dBu)

Phantom Power: Mic Pin2/Pin3 and Pin1 48±2V

UK/Australia: 240 VAC 50 Hz

Europe: 210-240 VAC 50 Hz

Power Consumption: 50 W

Fuse: 1.25 A

Main Connection: Standard IEC receptacle
