NUX Modelling Processor Amp Academy Stomp NMA-3AAP

– Pedal Type: Amp Modeling, Multi-FX

– Analog/Digital: Digital

– Presets: 27 x Factory, 27 x User

– Number of EFX blocks: 9 (NG, CMP, EFX, AMP, EQ, S/R, IR, DLY, RVB)

– Impulse Responses: Left & Right, 60 x Factory Cyber IRs, 40 x User IRs

– USB: USB-C for 24-bit / 48 kHz USB AUDIO, USB MIDI (PC Editor), firmware update, NBT-1 Bluetooth Module with APP control

– Bluetooth: Additional NBT-1 Bluetooth Module with APP control

– Expression Control: Yes, external EXP or additional NMP-2 Lite footswitch

– Bypass Switching: Buffered Bypass

– Software: Amp Academy Stomp editor (PC), Amp Academy Stomp APP

– INPUT/RETURN Impedance: 1MΩ

– AUX IN Impedance: 10 kΩ

– OUTPUT L/R Impedance: 100 Ω (balanced)

– SEND Impedance: 1 kΩ

– PHONES OUT Impedance: 10 Ω

– INPUT to OUTPUT L/R Dynamic Range: 111 dB

– Sampling Rate: 48 kHz / 32-bit

– System Latency: Minimum 2 ms

– Power: 9V DC (center negative)

– Current Draw: < 500 mA

– Dimensions: 183 (L) x 130 (W) x 65.3 (H) mm

– Weight: 0.9 kg/1.98 lbs
